- PP and PVDF solid construction
- T max exercise: PP 75°C- PVDF 98°C
- Sleeved SS316 or Titanium shaft
- Connections: Threaded or Socket union
- Gaskets: EPDM for PP, FPM for PVDF
- Pump body with threaded closure system, No bolts
- Single or Three phase electric motor with extended shaft
- Optional PP Drip Proof Motor Fan Cover
PUMP IDENTIFICATION
Model
Pump body
Shaft
Impeller type
Oring
Connections
Motor/Rpm
Optionals
EXPLODED VIEW EASY PUMP
Part. N. Description
1 Motor
2 Nut
3 Socket union (std. PVDF)
4 MIMM sealing
5 Outlet pipe
6 Bolt
7 Pump housing
8 Elbow
10 Impeller set
11 Pump housing O-ring
12 Pump head
13 Pump flange
14 Ogive
