REVERSE OSMOSIS DEMINERALIZER

REVERSE OSMOSIS DEMINERALIZER ( 60-130 )

Skid - Elegant fairing in glazed stainless steel (aisi 304) with strong base in stainless steel (aisi 304) tubular.

Pre-filtration - Cartridge with washable net, filtration 60 micron

De-chlorination - Activated charcoal cartridge containing approximately lt 3,5 of activated charcoal

Micrometrical filter - Filtering cartridge 5 micron

Antiscalant - Electronic proportional metering pump with membrane and tank for the preparation of antiscalant dosage

solution.

Inlet - Solenoid electro-valve and safety switch

Pressurization - Volumetric pump with mono-phase motor 0,45 kw with thermal safety

Membranes - Wound Membranes in polyamide Diameter 2,5”, length 40”, minimum saline rejection 99,5%

Pressure vessels - In stainless steel

Pressure indicators - n. 2 pressure gauge in glycerine

Delivery indicators - n. 2 flowmeter for the delivery control: permeat outlet, concentrated discharge

Conductibility control - Digital electronic conductivity meter with adjustable alarm with functioning shut off for high

Conductibility (disconnectable)

Functioning control - Electric panel in elegant case in ABS containing control switchboard with digital conductivity meter.

LCD panel back-illuminated, visual display unit of appropriate and specific messages with automatic stop in case of :

- High level storage tank treated water

- Low pressure inlet

- High conductivity (disconnectable)

- Motor overheating

- Low antiscalant level

- External inhibition (there’s a specific inlet contact)

- Eventual automatic filter during washing
